ITEM SPECIFICATIONS

• Design
  Reducer
• Box Qty
  10
• Connection Size - Port 1
  1/4 in
• Connection Type - Port 2
  Push-to-Connect Imperial
• Connection Size - Port 2
  5/32 in
• Connection Type - Port 1
  Push-to-Connect Imperial
• Internal Hex
  No
• Material - Body/Non-threaded Portion
  Nickel-plated Brass
• Material - Collar
  Nickel-plated Brass
• Operating Pressure Complete Temperature Range (Metric)
  -0.95 - 10 bar
• Operating Pressure Complete Temperature Range (Standard)
  -13.78 - 145.04 psi
• Operating Temperature (C)
  -20 to 80° C
• Operating Temperature (F)
  -4 to 175° F
• Size
  Standard
